Leaf chains are steel chains using a simple pin construction and link plate. The chain number refers to the lacing of the links and the pitch. The chains have certain features like for example high tensile strength for each section area, that enables the design of smaller devices. There are A- and B- type chains in this particular series and both the BL6 and AL6 Series comprise the same pitch as RS60. Lastly, these chains cannot be powered with sprockets.
In roller chains, the link plates have a higher fatigue resistance because of the compressive tension of press fits, yet the leaf chain only has two outer press fit plates. On the leaf chain, the maximum acceptable tension is low and the tensile strength is high. If handling leaf chains it is essential to consult the manufacturer's instruction booklet so as to guarantee the safety factor is outlined and utilize safety measures at all times. It is a better idea to carry out extreme caution and use extra safety measures in functions where the consequences of chain failure are serious.
Using more plates in the lacing leads to the higher tensile strength. Because this does not improve the maximum permissible tension directly, the number of plates utilized can be limited. The chains require frequent lubrication as the pins link directly on the plates, producing a very high bearing pressure. Making use of a SAE 30 or 40 machine oil is normally suggested for the majority of applications. If the chain is cycled more than one thousand times every day or if the chain speed is over 30m for every minute, it will wear extremely fast, even with continuous lubrication. Therefore, in either of these situations utilizing RS Roller Chains would be much more suitable.
AL type chains are only to be used under certain situations like for example where there are no shock loads or when wear is not a huge problem. Make certain that the number of cycles does not exceed a hundred every day. The BL-type would be better suited under other conditions.
The stress load in parts would become higher if a chain using a lower safety factor is chosen. If the chain is also utilized among corrosive situations, it can easily fatigue and break very quick. Performing frequent maintenance is really important if operating under these types of conditions.
